Keyboard
|
Number of keys
|
88
|
|
Key action
|
Tri-Sensor Scaled Hammer Action Keyboard II
|
|
Key surface finish
|
Simulated ebony and ivory keys
|
|
Touch response
|
3 sensitivity levels, off
|
|
Tones
|
Polyphony (maximum)
|
128
|
|
Number of built-in tones
|
18 built-in tones
|
|
Sound source
|
Multi-dimensional Morphing AiR
|
|
Stereo-sampled piano tones
|
Yes
|
|
Layer/Split
|
Yes/Yes
|
|
Simulator
|
Hammer Response
|
Yes
|
|
Damper Resonance
|
Yes
|
|
Digital effects
|
Types
|
Reverb
|
4
|
|
Chorus
|
4
|
|
Brilliance
|
Yes (-3 ~ 0 ~ 3)
|
|
DSP
|
Yes (preset for some tones)
|
|
Songs
|
Number of built-in songs
|
60 songs
|
|
Demonstration-only songs
|
-
|
|
Song expansion (user songs)
|
10 songs (max.) up to approximately 90KB/song
|
|
Additional features
|
Lesson function
|
Part on/off
|
|
Lesson part select
|
Right hand, left hand
|
|
Recorder
|
2 tracks, 1 song
|
|
Approximate data capacity
|
Approximately 5,000 notes total
|
|
Audio recording/playback
|
-
|
|
Duet mode
|
Yes
|
|
Octave shift
|
±2 octaves
|
|
Metronome
|
0, 2, 3, 4, 5, 6 beats; tempo range: 20 to 255
|
|
Pedals
|
Included: SP-3 Optional: SP-20, SP-33 (damper, soft, sostenuto)
|
|
Half-damper pedal operation
|
Yes (with optional SP-33 3-pedal unit)
|
|
Transpose
|
2 octaves (-12 semitones ~ 0 ~ +12 semitones)
|
|
Tuning control
|
A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
|
|
Scale function
|
Number of preset temperaments
|
17
|
|
Operation lock
|
Yes
|
|
MIDI
|
|
Yes
|
|
|
Connectivity and storage
|
Phones
|
2 (stereo mini jack)
|
|
Pedal
|
1 (Damper)
|
|
Connector for 3-pedal unit
|
Yes
|
|
USB port
|
Yes
|
|
Line OUT
|
R, L / Mono Standard jacks 6,3 mm
|
|
Dimensions
|
Size/wattage
|
12 cm x 2/8 W + 8 W
|
|
Size
|
Size (w x d x h)
|
1,322 x 286 x 135 mm (w/o music stand)
|
|
[with optional stand]
|
[1,322 x 286 x 760 mm]
|
|
Weight
|
Weight
|
11.1 kg (w/o music stand)
|
|
[with optional stand]
|
[21.1 kg]
|
|
Accessories
|
Included accessories
|
Pedal (SP-3), AC adaptor (ADA12150LW), music stan
|
