Keyboard
|
Number of keys
|
88
|
|
Key surface finish
|
Simulated ebony and ivory keys
|
|
Velocity resolution
|
16.256 maximum
|
|
Layer/Split
|
Yes/Yes
|
|
Duet
|
4 octaves (-2 to 0 to +2)
|
|
Transpose
|
2 octaves (-12 to 0 to +12)
|
|
Octave shift
|
4 octaves (-2 to 0 to +2)
|
|
Sound source
|
Number of tones
|
650
|
|
Polyphony (max.)
|
256 tones
|
|
Touch response
|
3 sensitivity levels, off
|
|
Tuning
|
415,5 Hz to 440,0 Hz to 465,9 Hz (0,1-Hz units)
|
|
Temperament
|
17 types
|
|
Display
|
Functions: 5,3 inch LCD touch panel
|
|
Acoustic Simulator
|
Linear Morphing, Hex-Layer
|
Yes
|
|
Damper Resonance
|
Yes (16 levels)
|
|
Hammer response
|
Yes (8 levels)
|
|
String resonance
|
Yes (16 levels)
|
|
Effects
|
Types
|
Hall: 17 types
|
|
Chorus: 16 types
|
|
Delay: 6 types
|
|
DSP: 20 types
|
|
Master EQ: bands parametric
|
|
Auto Accompaniment
|
Data items
|
Presets: 220
|
|
User: 30
|
|
Music Preset
|
Data items
|
Presets: 305
|
|
User: 100
|
|
Demo Song
|
Number of songs
|
6
|
|
MIDI Recorder
|
Functions
|
Real-time recording: Yes
|
|
Playback: Yes
|
|
Songs
|
Number of songs: 100
|
|
Number of tracks: 17
|
|
Capacity: Up to appr. 50.000 notes per song
|
|
Recorded data protection
|
Built-in flash memory
|
|
MIDI recorder volume level
|
Adjustable
|
|
Audio Recorder
|
Functions
|
Real-time recording: Yes, USB flash drive
|
|
Playback: Yes, USB flash drive
|
|
Songs
|
Number of songs: 100
|
|
Length: Approximately 74 minutes maximum recording per file
|
|
Registration
|
96 (4 setups x 24 banks)
|
|
Metronome
|
Beats
|
0 to 9
|
|
Tempo range
|
20 to 255
|
|
Metronome volume level
|
Adjustable
|
|
Pedal
|
Damper (with half-pedal operation): Yes
|
|
Soft: Yes
|
|
Sostenuto: Yes
|
|
Other functions
|
Dedicated piano tone buttons
|
Yes
|
|
Balance adjustment
|
Yes
|
|
Setting backup
|
Yes
|
|
Operation lock
|
Yes
|
|
MIDI
|
16-channel multi-timbre receive
|
|
Pitch Bend + Modulation Wheels
|
Yes
|
|
USB Flash Drive
|
Capacity
|
32 GB
|
|
Inputs/Outputs
|
Phones: Stereo mini jacks x 2
|
|
Pedal: standard jacks x 2
|
|
Line IN: (L/MONO, R) standard jacks x 2
|
|
Line OUT: (L/MONO, R) standard jacks x 2
|
|
Audio-Input: Stereo mini jack
|
|
USB port: Type B
|
|
USB flash drive port: Type A
|
|
Optional pedal connector for SP-33: Yes
|
|
Speakers
|
Size
|
12 cm x 2 + 5 cm x 2
|
|
Output
|
8 W + 8 W
|
|
Power Requirements
|
AC adaptor
|
AD-A12150LW
|
|
Auto power off
|
Appr. 4 hours after last operation
|
|
Power Consumption
|
12 V - 10 W
|
|
Dimensions
|
W x D x H
|
w/o stand and music stand: 132.2 x 29.3 x 14.7 cm
|
|
Weight
|
w/o stand and music stand: approximately 12 kg
|
|
Accessories
|
included
|
Pedal (SP-3), AC adaptor (AD-A12150LW), music stand
|
